Double Face Magic Panel Matrix LED Moving Head with Wash Zoom & Strobe

Short Description:

2540DZ- Magic panel matrix moving head has a double face, wash zoom and strobe face, it is an innovative professional stage lighting and was launched into the market in 2019. This model shared with the same body can make with two version lights, double face or single face with wash zoom only.

It generates an ultra-tight 3.5° beam from each of the 25 pixels, pixels effect make it allow to display letters, numbers, arrows, etc patterns. The patterns can be moved forward or backward, plus Pan & Tilt is quickly moving with infinite rotating, creating an excellent 3D dynamic effect.

Brand: Beyond

Model: 2540DZ

Warranty: 2 Years

Email: beyond03@beyond58.com

WhatsApp/WeChat: 8613922297736

Send email to us Product Manual

Product Detail

Double Face 25x40W Wash Zoom & 576x0.2W LED Strobe Magic Panel Light

This matrix magic panel light is a two-face LED moving head, the total has 25 LEDs, each LED is 40W RGBW 4-in-1 colors, and used high quality and high output new design optic. The illuminance data @ 5M on a 3.5° beam angle is 55,500 Lux. Each LED can be controlled individually, a total of 25 pixels, and can create a very rich pattern effect, such as letters, numbers, arrows, and graphs that can rotate forward or backward.

With a motorized linear zoom angle from 3.5° to 45°, it has a very sharp beam and smooth & uniform wash colors. Three-phase step motor gives the good ability for quick infinite rotating of pan and tilt. In terms of details, the housing is equipped with fixed locks for Pan and Tilt, which can keep the fixture stable during disassembly and installation without shaking.

2540DZ magic panel light can also be made single-sided, with the strobe removed. Other features are the same as the double-sided version

As high-level professional lighting, it has 16-bit dimming, no flicker, and is suitable for the theatre and TV station. The preset is richly colored and Marco's function is. 5 DMX channel modes meet the programming needs of different scenarios and are controlled by RDM, DMX512, and Art-net protocol.

More importantly, we take over 1 year to test it during our Research and development process, the light featured heat protection, over-current protection, and over-voltage protection, to ensure they are working stable and in good performance.

Technical Parameters

Light Source: 25 x 40W 4in1 RGBW LED,576 x 0.2W 4in1 RGBW

LED Lifetime: ≥ 50000H

Power Voltage: AC100-240V, 50-60Hz

Power Consumption: 1100W,Power factor PF ≥ 0.95

Beam Angle: 3.5°~45°,Glass light guider + PMMA high quality optical lens

Control Modes: DMX512/ Auto/ Sound/ Master/ Manual/ RDM/ ArtNet（optional）

DMX Channel: 26/ 33/ 43/ 143/120 Channel

Protection Rating: IP20

Display: 2.4°TFT Color Display, Chinese and English modes can be switched, and can be rotated 180 degrees

Data In/Out Socket: 3-pin & 5-pin XLR sockets

Security protection: Over current, over voltage, and overheat protection

Power Socket: Power-Con in/ out

Housing Material: ABS High temperature resistant plastics

Pan:540°,Accuracy 2.11°/step, fine-tuning accuracy: 0.008°

Tilt: 270°,Accuracy 0.86°/step, fine-tuning accuracy: 0.0034°

Photoelectric reset system: Pan & Tilt infinite rotation;

MAX. Connection: 4 units（240V，50Hz） 2.5mm² power cable; 2 units（100V，60Hz） 2.5mm² power cable

Dimension: 420 mm*272 mm*599.5 mm

Net Weight: 24kg

Carton Package: 530mm*420mm*600mm 1in1 GW: 28 kg

Flight Case: 780mm*495mm*760mm 2in1 GW: 84.5 kg

Features: Full light range dimming, 65536-level dimming accuracy. Fast strobe 1-25Hz.LED single control, can display numbers, letters, arrow,s and other graphics ;Preset multiple color macros; Preset multiple effect macros

Configuration: Signal cable 1pc; Power cable 1pc; Manual 1pc;
