Beyond 900W Wind Fire Wheel

Light Source: 1x 220W 4IN1 RGBW LED; 12x 60 W 4IN1 RGBW LED; 48x 0.1 W 4IN1 RGB LED;

LED Lifetime: ≥ 50000H

Power Consumption: 980±5%W,Power factor PF≥0.95; Standby power: 22.5W

Power Voltage: AC100-240V，50-60Hz

Beam Angle: Ring Beam Angle:4°~ 40°,Center Beam Angle:4.5°~ 28°,Glass light guider + PMMA high quality optical lens

Control Modes: DMX512/ Auto/ Sound/ Master/ Manual/ RDM/ Art Net(optional)

DMX Channel: 37/ 38/ 47/ 75 Channel

DMX+ART NET DMX Channel: 22+52 Channel

Protection Rating: IP20

Display: 1.8°TFT Color Display,Can rotate 180 degrees, switch between Chinese and English

Data In/Out Socket: 3-pin & 5-pin XLR sockets

Working temperature: -10℃～45℃

Security protection: Over-current, over-voltage, over-heat

Power Socket: Power-Con in/ out

Housing Material: ABS High temperature resistant plastics

Electronic control technology: Menu or console control facility reset; 0-100% dimming; constant current drive mode; temperature sensor detection, intelligent adjustment of light source power; facility information query; intelligent fan speed regulation; magnetic encoding positioning system.

Pan: 540° (16bit accurate scanning)

Tilt: 270° (16bit accurate scanning)

MAX. Connection: 4 units（240V，50Hz） 2.5mm²  power cable; 2 units（100V，60Hz） 2.5mm²  power cable;

Dimension: 421mm*311.1mm*545mm  Net Weight: 24kg;

Carton Package: 595mm*400mm*510mm  1in1  GW: 28kg;

Flight Case: 880mm*495mm*770mm 2in1  GW: 82.18 kg;

Features: Full light range dimming, 256-level dimming accuracy; fast strobe 1~25Hz; LED single control; preset multiple color macro functions, 200W lamp beads can image rotation/frost; preset multiple effects (WASH, Single control, strobe) macro functions

Attention: As soon as the facility is powered on and self-tested, it will enter the locked screen state, or when there is no operation on the screen, the screen will automatically turn off and enter the locked screen state. The unlock password is up＋down＋up＋down

Configuration: Signal cable 1pc; Power cable 1pc; Manual 1pc;
